11121 11131
三角圆柱形粉刚玉带柄磨头 球形粉刚玉带柄磨头

轴 Ø 6 x 40 mm 轴 Ø 6 x 40 mm
EN 12413 EN 12413

Ø h max. rpm
mm mm Lo=13 mm   Ø h max. rpm
11121 6 25 100.700 AR60P5V 25 111210007 mm mm Lo=13 mm  
11121 12 20 79.500 AR60P5V 25 111210012 11131 10 10 95.400 AR60P5V 25 111310010
11121 20 25 46.100 AR46P5V 25 111210020 11131 15 15 63.600 AR60P5V 25 111310015
11121 25 25 37.200 AR36/46P5V 25 111210025 11131 20 20 47.700 AR46P5V 25 111310020
11121 30 30 26.200 AR36/46P5V 25 111210030 11131 25 25 37.200 AR36/46P5V 25 111310025
11131 30 30 26.200 AR36/46P5V 25 111310030
11125 11132
圆头圆柱形粉刚玉带柄磨头
球形粉刚玉带柄磨头

轴 Ø 6 x 40 mm
EN 12413 轴 Ø 6 x 80 mm
EN 12413

Ø h max. rpm
mm mm Lo=13 mm  
11125 6 20 117.700 AR60P5V 25 111250006 Ø h max. rpm
11125 25 25 37.200 AR36/46P5V 25 111250025 11132 mm mm Lo=13 mm AR60P5V  
25 111320010
10
10
95.400
11125 30 50 15.100 AR36/46P5V 10 111250030 11132 15 15 63.600 AR60P5V 25 111320015
11125 40 40 14.700 AR36P5V 10 111250040 11132 20 20 47.700 AR46P5V 25 111320020
11130 11135
球形粉刚玉带柄磨头 碟形粉刚玉带柄磨头

轴 Ø 3 x 37 mm 轴 Ø 6 x 40 mm
EN 12413 EN 12413

Ø h max. rpm
mm mm Lo=13 mm   Ø h max. rpm
11130 6 6 124.900 AR60P5V 25 111300006 mm mm Lo=13 mm  
11130 8 8 84.800 AR60P5V 25 111300008 11135 30 6 31.800 AR60P5V 25 111350030
11130 10 10 60.100 AR60P5V 25 111300010 11135 40 10 23.800 AR36/46P5V 25 111350040
