11100 11102
圆柱形粉刚玉带柄磨头 圆柱形粉刚玉带柄磨头

轴 Ø 3 x 37 mm 轴 Ø 6 x 80 mm
EN 12413 EN 12413

Ø h max. rpm
mm mm Lo=13 mm  
11100 4 8 130.000 AR60P5V 25 111000004
11100 6 10 93.100 AR60P5V 25 111000006
11100 8 12 64.500 AR60P5V 25 111000008 Ø h max. rpm
11100 10 10 60.100 AR60P5V 25 111000011 11102 mm mm Lo=13 mm AR60P5V  
25 111020008
100.500
8
20
11100 10 12 52.700 AR60P5V 25 111000012 11102 10 15 95.400 AR60P5V 25 111020010
11100 12 15 37.300 AR60P5V 25 111000013 11102 10 30 62.200 AR60P5V 25 111020020
11102 12 15 79.500 AR60P5V 25 111020022
11102 15 15 63.600 AR60P5V 25 111020035
11101 11102 15 30 51.000 AR46P5V 25 111020040
圆柱形粉刚玉带柄磨头 11102 20 30 38.900 AR46P5V 25 111020060
11105
轴 Ø 6 x 40 mm 三角圆柱形粉刚玉带柄磨头
EN 12413

轴 Ø 6 x 40 mm
EN 12413

Ø h max. rpm
mm mm Lo=13 mm  
11101 4 8 130.000 AR60P5V 25 111010004
11101 5 10 130.000 AR60P5V 25 111010005
11101 6 10 130.00 AR60P5V 25 111010006
11101 8 10 119.300 AR60P5V 25 111010008
11101 10 10 95.400 AR60P5V 25 111010010
11101 10 15 95.400 AR60P5V 25 111010011
11101 10 20 86.600 AR60P5V 25 111010012 Ø h max. rpm
11101 10 25 72.700 AR60P5V 25 111010013 mm mm Lo=13 mm  
11101 10 32 58.700 AR60P5V 25 111010014 11105 20 65 16.200 AR36/46P5V 25 111050020
11101 12 10 79.500 AR60P5V 25 111010015
11101 12 15 79.500 AR60P5V 25 111010016
11101 12 20 79.500 AR60P5V 25 111010017
11101 15 3 63.600 AR60P5V 25 111010018 11106
11101 15 15 63.600 AR60P5V 25 111010019 平头锥形粉刚玉带柄磨头
11101 16 20 59.600 AR46P5V 25 111010020
11101 16 25 56.900 AR46P5V 25 111010021
11101 16 32 45.100 AR46P5V 25 111010022
11101 20 4 47.700 AR60P5V 25 111010023 轴 Ø 3 x 37 mm
11101 20 15 47.700 AR46P5V 25 111010024 EN 12413
11101 20 20 47.700 AR46P5V 25 111010025
11101 20 25 46.100 AR46P5V 25 111010026
11101 20 30 38.900 AR46P5V 25 111010027
11101 20 40 29.00 AR46P5V 25 111010028
11101 25 10 38.100 AR60P5V 25 111010030
11101 25 25 37.200 AR36/46P5V 25 111010031
11101 25 40 23.300 AR36/46P5V 10 111010032
11101 30 10 31.800 AR60P5V 25 111010034
11101 30 30 26.200 AR36/46P5V 25 111010035
11101 30 40 19.500 AR36/46P5V 10 111010036
11101 32 20 29.800 AR36P5V 25 111010037
11101 32 32 23.100 AR36P5V 10 111010038
11101 40 10 23.800 AR36/46P5V 25 111010041
11101 40 20 23.800 AR36P5V 10 111010042
11101 40 25 23.400 AR36P5V 10 111010043
11101 40 30 19.700 AR36P5V 10 111010044
11101 40 40 14.700 AR36P5V 10 111010045
11101 50 15 19.000 AR36P5V 10 111010051 Ø h max. rpm
11101 50 25 18.800 AR36P5V 10 111010052 mm mm Lo=13 mm  
11101 60 10 15.900 AR36P5V 10 111010060 11106 6 10 93.100 AR60P5V 25 111060006

 541
