866PZ 866RTX 867XZN/L
米字旋具头 中孔花型旋具头 加长型XZN®十二角旋具头

 L
 L   L
 

ISO 1173 C 8
ISO 2351-2 L
 mm   L
ISO 1173 C 8 T40 30 10 008660520  mm  
L T45 30 10 008660525 M5 75 5 008670255
PZ mm   T50 30 10 008660530 M6 75 5 008670256
1 32 10 008660300 T55 30 10 008660535 M8 75 5 008670258
2 32 10 008660305 T60 30 10 008660540 M10 75 5 008670260
3 32 10 008660310 T70 30 10 008660545 M12 75 5 008670262
4 38 10 008660315

866PE 867PE 867TX
六角旋具头 花型旋具头
六角旋具头

 L  L  L
  

ISO 2351-3
ISO 1173 C 8
L L L
mm mm   mm mm    mm  
3 30 10 008660100 4 30 5 008670104 T20 30 5 008670400
4 30 10 008660105 5 30 5 008670105 T25 30 5 008670405
5 30 10 008660110 6 30 5 008670106 T30 30 5 008670410
6 30 10 008660115 7 30 5 008670107 T40 30 5 008670415
7 30 10 008660117 8 30 5 008670108 T45 30 5 008670420
8 30 10 008660120 10 30 5 008670110 T50 30 5 008670425
10 30 10 008660125 12 30 5 008670112 T55 30 5 008670430
12 30 10 008660132
14 30 10 008660134
867PE/L 867TX/L
加长型花型旋具头
866TX
加长型六角旋具头
花型旋具头
 L  L
 
L


L L
mm mm     
ISO 1173 C 8 4 75 5 008670154 T20 mm 5 008670450
75
5 75 5 008670155 T25 75 5 008670455
L 6 75 5 008670156
 mm   7 75 5 008670157 T30 75 5 008670460
T20 30 10 008660400 8 75 5 008670158 T40 75 5 008670465
T25 30 10 008660405 10 75 5 008670160 T45 75 5 008670470
T27 30 10 008660410 12 75 5 008670162 T50 75 5 008670475
T30 30 10 008660415 T55 75 5 008670480
T40 30 10 008660420
T45 30 10 008660425
T50 30 10 008660430
T55 30 10 008660435 867XZN 867RTX
T60 30 10 008660440
T70 30 10 008660445 XZN®十二角旋具头 中孔花型旋具头
 L  L
 

L
 mm  
L
 mm   T20 30 5 008670500
M4 30 5 008670204 T25 30 5 008670505
M5 30 5 008670205 T30 30 5 008670510
M6 30 5 008670206 T40 30 5 008670515
M8 30 5 008670208 T45 30 5 008670520
M10 30 5 008670210 T50 30 5 008670525
M12 30 5 008670212 T55 30 5 008670530
